AST2500

AST2500 is ASPEED's 6th generation Server Management Processor. With the 800MHz ARM11 processor and the mainstream double data rate memory migrating from DDR3 to DDR4, AST2500 provides customer the best performance server management solution. In additional to the advanced BMC features, the on chip PCIe 2D VGA provides server systems with local display capability without adding extra cost for VGA add-on card. The embedded ARM11 and DDR4 1600Mbps meet the increasing performance requirements of the server system.
Product Name | AST2500 Advanced PCIe Graphics & Remote Management Processor |
Features |
|
Related Products | AST2510 / AST2520 |
Media Review Sections |
Embedded CPU | 800MHz ARM11 |
SDRAM Memory |
|
Flash Memory | SPI flash memory |
Video-Over-IP |
|
USB-Over-IP |
|
BMC | Yes |
VGA |
|
VGA Drivers |
|
LAN | Dual 10/100/1000M bps MAC |
Technology | 456-pin 19mmx19mm TFBGA package |
Pin Compatibility | AST2510, AST2520 |
